136 to 520MHz 2 Way Power Divider

5o319470 Achieve Flawless Signal Splitting and Combining with Our 136-520MHz 2-Way Power Divider

Precision and reliability are paramount in RF signal management. Our robust 2-Way Power Divider is engineered to deliver exceptional performance across the critical 136 to 520MHz band, making it the ideal choice for a wide range of military, commercial, and public safety applications.

This versatile component excels in both splitting a single input into two balanced outputs and combining two signals into a single output. It features a high power handling capacity of 50 Watts as a splitter and 2 Watts as a combiner, ensuring durability in demanding environments.

Application

Wireless communication system.

Radar and satellite systems.

Testing and measuring equipment.

Other special applications: harmonic suppression, electronic countermeasure, etc.

It supports a one-year standard warranty.

Product Highlights:

Broad Frequency Range: 136 – 520 MHz

High Isolation: >18 dB minimizes interference between ports

Excellent Match: VSWR < 1.35 for superior signal integrity

Low Loss: Insertion Loss < 1.1 dB (including 3dB theoretical split loss)

Outstanding Balance: ±3° phase and ±0.8dB amplitude unbalance

Robust Connectivity: Your choice of SMA or N-type connectors

High Power Handling: 50W (Splitter) / 2W (Combiner)

 Ideal for land mobile radio, military communications, and signal distribution in complex systems, this power divider guarantees consistent performance. Ensure your system operates with maximum efficiency and reliability.

Datasheet
